Single Waste Bin Double Waste Bin

FACEFRAME CABINET FRAMELESS CABINET FACEFRAME CABINET FRAMELESS CABINET
a r F m e c d a n i b t e a r F m c s s e l e a n i b t e a r F m e d c a n i b t e a r F m e l e s s c a n i b t e
22 ⅛"
≥22 ¹⁄₈ " 22 ⅛"
≥22 ¹⁄₈ "

A A
A A A A
A A

SINGLE WASTEBIN PULLOUT DOUBLE WASTEBIN PULLOUT

1 CHOOSE A FRAME TO FIT YOUR CABINET WASTEBIN PULLOUT

Choose a single or double pullout available in 3 colors

Faceframe Frameless
Description Dimensions A min A min champagne chrome silver

Single wastebin pullout frame 2505840103 2505840005 2505840102
12 ¼" W x 22" D x 10" H 11 ½" 12 ½"
Single wastebin pullout frame bulk (16 units) 2505850103 2505850005 2505850102
Double wastebin pullout frame 2505860103 2505860005 2505860102
15 ¼" W x 22" D x 10" H 14 ½" 15 ½"
Double wastebin pullout frame bulk (16 units) 2505870103 2505870005 2505870102

ORDER WASTEBINS + LIDS
2 Choose from 2 sizes in 3 colors

Description Dimensions Minimum internal height champagne white gray
36 quart plastic wastebin 14" W x 10 ½" D x 18" H 19 ½" 2503940103 2503949010 2503947930
52 quart plastic wastebin 14" W x 10 ½" D x 22" H 23 ½" 2505530103 2505539010 2505537930
Wastebin lid 10 ½" W x 14 ½" D x 1" H add 1" to above 2507910103 2507919010 2507917930
NOTE For double Wastebin Pullout, please order one lid. To be used on front bin only.

3 ADDITIONAL INSTALLATION HARDWARE

See below for details

PUSH-TO-OPEN KIT Accessories champagne silver
+ Mechanical operation- no need for electricity Push-to-Open
+ Minimal modification to Wastebin Pullout (requires ⅛" additional internal cabinet depth) 2507900103 2507900102
frame installation Wide door bracket
+ Easy to retrofit with v-frame pullout (for doors wider than 21") 2507920103 2507920102
+ Can be operated with or without door handles
