Page 13 - KESSEBÖHMER-Product_Catalogue

=
=
min 1/4”
door
shelf
width
= door opening min 1/4” max = opening - 2x1/4”
=
1 ORDER A RUNNER X door opening
Includes runner mechanism
Pullout travel Clear inside depth gray USE THIS FORMULA WHEN DOOR HINGES CAN’T max door - 2x(+1/4”)X
shelf
min 1/4”
18 ½" ≥ 20" 2503667930 BE MOUNTED ABOVE OR BELOW THE SHELF. width = opening
MAX SHELFWIDTH = DOOR OPENING - 2( X + ¼")
SELECT A SUPPORT POST

2 Internal cabinet height must be taller than support post height
= =
Min. Internal Height Installed Height Support post height silver
door opening
59 ½" 51 ¼" 44 ½" 0023650102
x X
67 ⅜" 59 ⅛" 52 ⅜" 0023670102
75 ¼" 67" 60 ¼" 0023690102
max door LAVIDO
83 ⅛" 74 ⅞" 68 ⅛" 0023710102 shelf = opening - 2( + ⁄ ”)x
min 1/4” width
3 Choose from standard glass shelves, or customize your LAVIDO with ARENA Select.
ORDER SHELVES TO SUIT YOUR STYLE

4-SHELF SET
Includes 1 shelf with top runner, 3 height adjustable shelves,
and hardware. Shelf measures (W x 18 ½'' D X 3 ⅜'' H)
ARENA ARENA ARENA
Min. cabinet width Shelf width chrome/maple chrome/white chrome/anthracite
17 ⅝" 15 ¾" W 2503100005 2503020005 2506220005

19 ⅝" 17 ⅝" W 2503120005 2503040005 2506230005
23 ⅝" 21 ⅝" W 2503140005 2503060005 2506240005
SINGLE SHELF
Order a 4-shelf set and one to two single shelves for installed heights 59 ⅛'' - 74 ⅞''
ARENA ARENA ARENA
Min. cabinet width Shelf width chrome/maple chrome/white chrome/anthracite

17 ⅝" 15 ¾" W 2503290005 2503250005 2506250005
19 ⅝" 17 ⅝" W 2503300005 2503260005 2506260005
23 ⅝" 21 ⅝" W 2503310005 2503270005 2506270005

CUSTOMIZE
ARENA SELECT 4-SHELF SET
Designed to be paired with StraightLine wooden accessories
ARENA ARENA ARENA
Min. cabinet width Shelf width chrome/maple chrome/white chrome/anthracite
23 ⅝" 21 ⅝" W 2504680005 2504670005 2507690005

ARENA SELECT SINGLE SHELF
Order a 4-shelf set and one to two single shelves for installed heights 59 ⅛'' - 74 ⅞''
ARENA ARENA ARENA
Min. cabinet width Shelf width chrome/maple chrome/white chrome/anthracite
23 ⅝" 21 ⅝" W 2504710005 2504700005 2507700005

NOTE Refer to StraightLine catalog for wooden inserts and accessories for ARENA Select shelves
