A
DOOR SHELF

B B A REAR SHELF 8 1 / 2 " 22 1 / 2 "–24"
A B

NOTES 22 1 / 2 "–24" 22 1 / 2 "–24" 22 1 / 2 "–24" 22 1 / 2 "–24"
+ Faceframe application: A min. REAR SHELF REAR SHELF REAR SHELF
REAR SHELF
becomes the door opening
+ We recommend ordering
2 sets of shelves for the 45"
frame and 3 sets of shelves
DOOR SHELF DOOR SHELF DOOR SHELF DOOR SHELF
for the 67" frame.

TANDEM
8 1 / 2 " 8 1 / 2 " 8 1 / 2 " 8 1 / 2 "
A ± ¹/₂" A A + ¹/₂"

CHOOSE A FRAME SET
1 Includes frame, runners, door brackets, and integrated soft closers

Size A min B min Frame set champagne silver

15" W x 45" H 2501040103 2501040102
S 16 ½" 34 ½"
15" W x 67" H 2502410103 2502410102
18" W x 45" H 2501050103 2501050102
M 19 ½" 40 ½"
18" W x 67" H 2502420103 2502420102
21" W x 45" H 2501060103 2501060102
L 22 ½" 46 ½"
21" W x 67" H 2502430103 2502430102

2 ORDER REAR SHELVES

FOR YOUR UNIT
Each set contains 2 shelves
(W x 12'' D X 3 ½'' H)
ARENA classic ARENA classic ARENA classic ARENA style
Size Shelf width champagne/maple chrome/maple chrome/white chrome/anthracite
S 14 ⅞" W 2506640103 2506640005 2506700005 2850730005
M 17 ⅞" W 2506650103 2506650005 2506710005 2850740005
L 20 ⅞" W 2506660103 2506660005 2506720005 2850750005

3 ORDER DOOR SHELVES

FOR YOUR UNIT

Each set contains 2 shelves
(W x 6 ¾'' D X 3 ½'' H)
ARENA classic ARENA classic ARENA classic ARENA style
Size Shelf width champagne/maple chrome/maple chrome/white chrome/anthracite
S 11 ⅛" W 2506670103 2506670005 2506730005 2850760005

M 14 ⅛" W 2506680103 2506680005 2506740005 2850770005
L 17 ⅛" W 2506690103 2506690005 2506750005 2850780005

C LEVERST ORA GE.C OM C LEVERST ORA GE.C OM 11
