SWINGS LEFT SWINGS RIGHT
B B B B B B

NOTES
19 ¾" C C C C 19 ¾" + The minimum internal
cabinet height is 21 ½″
for standard, and 50''
for highboard kit
85°
85 85°° 85°
+ Four-way adjustable block
changes travel of shelves
+ Includes gauge for quick
A A A A A A and easy installation
1 Includes 2 shelves, 4 shelf support arms, LeMans II
ORDER A COMPLETE LEMANS SET

mounting post, hardware, and measuring gauge

A B ARENA classic ARENA classic ARENA classic ARENA style
Shelf min champagne/maple chrome/maple chrome/white chrome/anthracite
Faceframe: 14—16"
40er right 30 ¾" 2507420103 2507420005 2507440005 2850300005
Frameless: 14 ¼—16 ⅜"
Faceframe: 14—16"
40er left 30 ¾" 2507410103 2507410005 2507430005 2850290005
Frameless: 14 ¼—16 ⅜"
Faceframe: 16 ⅛—17 ⅝"
45er right 32 ¼" 2502680103 2502620005 2502740005 2850320005
Frameless: 16 ½—18 ¼"
Faceframe: 16 ⅛—17 ⅝"
45er left 32 ¼" 2502670103 2502630005 2502730005 2850310005
Frameless: 16 ½—18 ¼"
Faceframe: 17 ¾—21 ⅛"
50er right 36 ¼" 2502700103 2502600005 2502760005 2850340005
Frameless: 18 ⅜"—22 ⅛"
Faceframe: 17 ¾—21 ⅛"
50er left 36 ¼" 2502690103 2502610005 2502750005 2850330005
Frameless: 18 ⅜"—22 ⅛"
Faceframe: 21 ¼—24 ⅝"
60er right 38" 2502720103 2502640005 2502780005 2850360005
Frameless: 22 ¼—24 ⅝"
Faceframe: 21 ¼—24 ⅝"
60er left Frameless: 22 ¼—24 ⅝" 38" 2502710103 2502650005 2502770005 2850350005
2 ORDER ACCESSORIES / INSTALLATION HARDWARE

Customize LeMans to suit your needs

Accessory Description champagne chrome white gray
Soft-close mechanism For RIGHT side opening 2346419010 2346417930
For LEFT side opening 2346429010 2346427930

Lid rack 17 ¾" W x 5 ⅞" D x 1 ⅝" H 0069450103 0069450005
Restrictor clip Restricts travel of shelves 2501071918 2502667930
19 ¾" H
Shim (faceframe only)
3 OPTIONAL HIGHBOARD KIT

Order 2 complete LeMans sets above plus the highboard kit for double the storage

Description champagne silver white
Tall post and profile connectors- 47 ¼" H 2504140103 2504140102 2504149010
